PS-200 Cabinet Power Supply

The PS-200 is a power supply for NEMA TS-2 cabinets that provides regulated direct current or unregulated alternating current as well as a baseline frequency.

Description

The PS-200 is a power supply for NEMA TS-2 cabinets that provides regulated direct current or unregulated alternating current as well as a baseline frequency. It powers the detection module, bus interface units (BIUs), load breakers and other auxiliary devices.

The PS-200 is covered by a total quality program and has been tested under extreme real-world conditions.

All NEMA TS-2 Type 1 and NEMA TS-2 Type 2 cabinets equipped with BIUs require this type of power supply.

Outlets

The PS-200 has 4 outlets:

  • +12 VDC at 2 A
  • +24 VDC at 2 A
  • +12 VAC at 0.25 A
  • Baseline frequency of 60 Hz

All three voltage outlets are protected against over-currents by fuses and against temporary surges by a 1,500-W eliminator.

Characteristics

  • Supply voltage: 89–135 VAC 60 Hz
  • Operating temperature range: -34 to +74 °C (-30 to +165 °F)
  • Dimensions: 135 mm (h) x 102 mm (w) x 211 mm (d) (5.3 x 4 x 8.3″)
